HIGH-PRESSURE COOLANT SYSTEMS

FILTRATION SYSTEM PAGE - ULTRAFLEX BASE MODEL-min (1)

Increase Throughput by 30% with CoolJet High-Pressure Coolant Systems!

The CoolJet high-pressure coolant system utilizes state-of-the-art technology, helping customers keep their machine tool spindles running and profits flowing!

  • Increase speeds and feeds by 20% or more
  • Increases coolant life and protects your machine tool with superior filtration
  • Increase tool life 3x to 10x
  • Smaller space-saving design and footprint than our competitors
  • Modular design allows unit build flexibility that our competitors can’t match
  • Easy to maintain - no tools needed or no downtime required for filter changes



The Benefits of High-Pressure Coolant

High-pressure coolant systems offer significant advantages in manufacturing. Firstly, HPC effectively removes heat from the cutting zone, by penetrating the vapor barrier which reduces thermal deformation preventing excessive wear and tear on your cutting tool leading to more precise and consistent machining results. Additionally, the high-pressure stream flushes away chips from the work surface, preventing chip re-cutting and potential damage to the workpiece and machine tool.

If you are milling, turning, grinding, or drilling, high-pressure cooling will help you with:

  • Improved Chip Management
  • Increased Speed & Feeds
  • Increased Tool Life
  • Superior Filtration to Increase Coolant Life
  • Improved Part Finishes

See CoolJet High-Pressure Coolant in Action

High-Pressure Face Milling

High-Pressure Boring

High-Pressure  Part Cutoff

High-Pressure Drilling

FULLY MODULAR - "Have it Your Way"

The most versatile and innovative high-pressure coolant system on the market.  Available in fixed and variable flows.

CoolJet Labeled Graphic-min

Increase Your Bottom Line with CoolJet HPC Systems

CoolJet UltraFlex®

The CoolJet Systems are Ideal High-Pressure Coolant Systems for Your Machine Tools

The UltraFlex® can be ordered with fixed or automatic variable volume and single or variable pressure settings. The UltraFlex® has two high-pressure outlets as a standard with up to 8 available, with a range of 300 psi to 3000 psi (20 Bar to 210 Bar) of pressure and volumes from 4gpm to 20gpm (15lpm to 80lpm). The UltraFlex® System will increase your facility's productivity.

Standard features of the UltraFlex® high-pressure coolant system include an onboard feeder pump, a large color touchscreen operator display, a 65gal / 250L clean tank, quad high-capacity quick-change 10-micron filters, interface cables, and hoses. They can be built for 240-volt or 480-volt power sources.  All this is a compact footprint of 24" x 56" x 63".

You can configure your  UltraFlex® unit filtration and add unit-integrated accessories like a 36,000 BTU Chiller, 850 CFM mist and smoke collector, oil skimmer, and Cyclonic or Magnetic filtration.

COOLJET HIGH PRESSURE PAGE - COOLJET ULTRAFLEX IMAGE

The CoolJet TL®

The CoolJet TL® is a fixed-volume, single-pressure unit.

The CoolJet TL® has one high-pressure outlet, with a range of 300 psi to 1000 psi (20 Bar to 70 Bar) of pressure and a 9gpm volume (36lpm).

Standard features of the CoolJet TL® high-pressure coolant system include an onboard feeder pump, color touchscreen operator display, dual-parallel 10-micron filters, interface cables, and hoses. They can be built for 240-volt or 480-volt power sources.

  • 9.5 gpm / 36 lpm fixed flow
  • Range of 300 psi
  • Single outlet
  • Dual parallel 10-micron bag filtration
  • Footprint: W - 24” x L - 32” x H - 35”
    W - 610 mm x L - 812 mm x H - 889 mm
  • Power to Spec — 230v / 460v / 400v KVA – 5.9

Unit Options:

  • Ethernet IP Machine Interface available
FILTRATION SYSTEM PAGE - COOLJET TL- Copy-min (1)
Available CoolJet Models
Ultraflex
 Series
Unit Series Volume Pressure Flow Type Unit Configuration Unit KVA Outlets
 Filtration Type
70-36 9gpm  36lpm 300-1000psi   20-70bar Fixed or Variable Base Model 10.85   2 Up to 8  10um Bag or 5um Cyclonic
Mist Collector 11.64
Chiller 21.20
Chiller & Mist Collector 22.00
70-60 16gpm 60lpm 300-1000psi   20-70bar Fixed or Variable  Base Model 14.38   2  Up to 8 10um Bag or 5um Cyclonic
Mist Collector 15.18
Chiller 24.66
Chiller & Mist Collector 25.46
55-75 20gpm 75lpm 300-750psi      20-55bar  Variable  Base Model  14.38  2 Up to 8 10um Bag or 5um Cyclonic
Mist Collector 15.18
Chiller 24.66
Chiller & Mist Collector 14.50
UD SERIES - DUAL HIGH-PRESSURE PUMP MODEL
70-36-2 19gpm 72lpm  300-1000psi   20-70bar  Fixed or Variable Base Model  17.74   4 Up to 8 10um Bag or 5um Cyclonic
 Mist Collector  18.53
 Chiller  28.10
 Chiller & Mist Collector  28.89
SWISS MODELS
140-20 5gpm  20lpm 300-2000psi   20-140bar  Fixed or Variable Base Model  11.25 2 Up to 8 10um Bag or 5um Cyclonic
Mist Collector 12.04
 Chiller  21.60
 Chiller & Mist Collector  22.40
210-15 4gpm   15lpm 300-3000psi   20-210bar Fixed or Variable Base Model 14.26 2 Up to 8 10um Bag or 5um Cyclonic
Mist Collector 15.06
Chiller 25.08
Chiller & Mist Collector 25.88
