BAR FEEDERS
.png?width=500&height=500&name=AUTOMATION%20(8).png "AUTOMATION (8)")
Drive Productivity & Efficiency
ATS Bar Feeders enable machine operators to spend time on production, rather than having to worry about stock.
- Industry-leading 3 year warranty!
- Bar Feeders that will increase productivity by up to 50%
- Run lathes unattended through breaks, evenings, and weekends
- Provides simple, quick-changeover, low-cost automation
- Over 10K units in the field
Run Lights Out
ML3 SERIES BAR FEED
| MODELS | ML3-565 | ML3-580 | ML3-595 |
|---|---|---|---|
| Min/Max Bar Diameter (inches) | 0.2" - 2.56" | 0.2" - 3.13" | 0.2" - 3.75" |
| Max Bar Length (inches) | 60" | ||
| Max Stroke (inches) | 65" | ||
| Approximate Changeover Time | Up to 2 minutes + spindle liner change | ||
| Materials Tray Capacity, 1” Diameter Bars | 25 Bars | ||
| Weight Net / Gross lbs. | 850/1260 | ||
| Reloading Driven by | Electric Motor | ||
| Feeding Driven by | 400W Servo Motor | ||
| Feeding Method | Feed to Turret, Serve Feed, Sub-Spindle Pull | ||
MD SERIES BAR FEED
| MODELS | MD-565 | MD-580 | MD-595 | MD-12.102 |
|---|---|---|---|---|
| Min/Max Bar Diameter (inches) | 0.2" - 2.56" | 0.2" - 3.13" | 0.2" - 3.75" | 0.5" - 4" |
| Max Bar Length (inches) | 60" | 72" | ||
| Max Stroke (inches) | 65" | 80" | ||
| Approximate Changeover Time | Up to 2 minutes + spindle liner change |
|||
| Materials Tray Capacity, 1” Diameter Bars | 25 Bars |
|||
| Weight Net / Gross lbs. | 850/1260 |
|||
| Reloading Driven by | Electric Motor |
|||
| Feeding Driven by | 400W Servo Motor |
|||
| Feeding Method | Feed to Turret, Serve Feed, Sub-Spindle Pull |
|||
| *Feeding tolerance: Servo =/-0.004” subject to bar condition and workholding. Feeding to turret & sub-spindle pull governed by lathe accuracy (+/-0.0005” typical) |
||||
INDUSTRY LEADING FEATURES
-
Easy to Use
- Systems are easy to read and easy to use
- One-screen setup that significantly reduces setup time
- Alarms are displayed in an understandable format.
-
Reliability by Design
- 100% Electrical Operation
- Two or Three servo motors run it all!
- Proven Mechanical Design
- Soft reload process eliminates shock, vibration, and noise
- 90% of bar stock mass is below bar centerline for maximum rigidity and balance
-
Productivity & Efficiency
- Simple Setup with All Lathes
- "Quick-setup wizard" prompts entry of 5 parameters in plain English
- Store 250 part setup programs for repeat jobs
- Bar feed automatically makes all mechanical adjustments for bar diameter and workpiece length
